Technical Specs
Input Voltage Range: MIN: 2S LiPo
MAX: 6S LiPo
Max Continuous Amperage at full throttle: 25 amps*
Max Voltage: 25.2V
BEC Voltage: 5.5 volts
BEC Output: 8 amp peak**
3 amp continuous
(always check servo draw prior to first flight)
Size: Width: 0.72" (18.2mm)
Length: 1.72" (43.7mm)
Depth: 0.32" (8.1mm)
Weight (w/wires): 0.63 oz. (17.9g)
0.28 oz (7.9g) without wires
Connectors: N/A
Items Needed for Operation:
  • Battery connectors (sold separately)
  • Motor connectors (sold separately)
Product Use Statements: N/A
Application Guidelines: N/A
Programmability: Fully programmable Castle feature set using Castle Link USB adapter (coupon for free Castle Link adapter included in package) and freely downloadable Castle Link Windows software.
Telemetry Link Capable: Yes, except Battery Current
Tech Notes: N/A
